Product Details:
|
| Name: | MMA Inverter Welder | Voltage(V): | Single Phase 110V Or 220V |
|---|---|---|---|
| Frequency: | 50/60Hz | N.W: | 1.8 KG |
| Current(A): | 120A | Warranty Time: | 1 Year |
| Highlight: | 120A MMA Inverter Welder,120A AC MMA Inverter Welder,120A arc stick welder |
||
1. Smart hand-held design patent,Compact size, light weight.
2. Press chuck for quick replacement of electrode.
3. Integration of machine and welding cable. Free welding anytime, anywhere.
4. Button control switch, effectively prevent welding errors.
5. Inside anti-stick,Easy to carry.
| Model: | ARC-160 |
| Input power Voltage Frequency(V,Hz): | AC220(single phase)±15%,50/60 |
| Rated input power capacity(KVA) : | 7 |
| No-load voltage(v): | 62 |
| Output current range.(A): | 20-160 |
| Rated output voltage(V): | 28 |
| Duty cycle (%)(25ºC): | 35 |
| No-load loss(w): | 40 |
| Efficiency(%): | 85 |
| Power factor (COSφ): | 0.93 |
| Insulation class: | F |
| Weight(KG): | 1.8 |
| Overall dimension(mm): | 235×75×235 |
| Case protection degree: | IP21S |
| Suitable diameter of rod(mm): | 1.6-2.5 |
FAQ
Q: What's your factory MOQ?
A: MMA Welder MOQ 200 ,TIG/MIG/PLASMA CUT MOQ50,Sample available.
Q: Can i customize my own Logo/carton/machine's color?
A: We are OEM factory ,LOGO and color design based on 300pcs, carton design based on 500pcs.
Q: I order goods for own use ,how to do it?
A: We are factory no retail.if you want to place a trial order,depending on inventory .For a small amount of goods, the shipping fees is really expensive,to be borne by the buyer.
Q: How long your lead time?
A: Generally,Around 7 to 35 Days,depend on the order.
1. Digital control, MCU technology, automatic parameter saving, IGBT inverter technology.
2. High frequency to guarantee lighter and smaller welder with higher efficiency.
