Home ProductsPortable Plasma Cutter

Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter

Certification
China Shenzhen Exlentech Welding Equipments Co., Ltd. certification
China Shenzhen Exlentech Welding Equipments Co., Ltd. certification
I'm Online Chat Now

Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter

Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter
Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter

Large Image :  Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter

Product Details:
Place of Origin: CHINA
Brand Name: EXLENTECH
Certification: CE,CCC
Model Number: CUT-40
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: USD110-USD190/PC
Packaging Details: Carton package:455×270×345mm
Delivery Time: Small quantity:3 days; OEM:30days
Supply Ability: 5000pcs/month

Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter

Description
Name: Single Phase Plasma Cutting Machine Input Voltage: 220v
Gas: Compressored Air Color: As Require
Brand: Follow Your Idea Cutting Thickness: 8mm
High Light:

MOSFET single phase plasma cutter

,

40A single phase plasma cutter

,

40A Portable Plasma Cutting Machine

Portable Single Phase Plasma Cutting Machine 40A MOSFET Inverter



Portable Plasma Cutter CUT-40 Single Phase 220V Max Cutting Thickness 7mm Plasma Cutting Machine



Portable cutting machine product characteristics:

1. MOSFET inverter and precision constant current feedback control technology, soft switch, DC output, 100 kHz of inverter frequency;

2. Wide working voltage range, strong adaptability to electricity power grid, high ability of interference resistance, automatic voltage compensation, stable cutting current and steady arc;

3. Compact structure, portable, energy saving, easy for maintenance

4. For CUT-40 and CUT-50, we also can provide 110v & 220v duel automatic input voltage shift.



Model CUT-40
Input power Voltage Frequency(V,Hz): AC220(single phase)±15%,50/60
Rated input power capacity(KVA): 4.8
No-load voltage(V): 230
Output current range.(A): 10-40
Rated output voltage(V): 96
Duty cycle (%)(25ºC): 60
No-load loss(w): 40
Arc-starting: H/F
Efficiency(%): 85
Power factor (COSφ): 0.93
Insulation class: F
Weight(KG): 9
Overall dimension(mm): 365×138×238
Case protection degree : IP21S
Air compressor displacement(S): 0.17
Fine cutting thickness(mm): 5
Max cutting thickness(mm): 12
Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter 0
Portable Single Phase Plasma Cutting Machine 40A MOSFET inverter 1

MOQ:

· The different products with different MOQ. Contact us with more details.

· If with stock, 1-5 sets could be acceptable as well.



Payment:

· TT payment would be preferred: usually 30% deposit and the balance before shipment

Delivery time:

· Around 20 days after confirming the payment

Sample Issue

  • Once price and order confirmed, we will be glad to send you the required samples for reference.

First time to use this kind of machine

· There is an English manual or guide video that show you how to use machine.

· If you still have any question, please contact us by e-mail /phone / online service.

If any problem with machine after receiving

  • 24 hours to support by E-mail/calling
  • Free parts could be sent to you in machine warranty period.

Why choose us?

  • We are welding machine MANUFACTURER,so we can offer better price and after-sale service and shorter delivery date.
  • We use all new components,IGBT tube, diode,capacitor and so on imported components.
  • We adopt SMT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of repairing,we just need to change the bad pcb board.
  • We provide Warranty period of 1 to 2 years for all our items.

Do you have any concerns about the after-sales service of the welding machines you buy?



We have a complete set of after-sales service system to ensure that you have no worries about purchasing.

1. We provide quality assurance service for up to 12 months wanrranty. The effective time of service is calculated form the date of purchase or Boarding date of BL.

2. For each order, we will provide 1% free PCB or key components for your maintenance.

3. If you encounter problems which can't be fixed by yourself, we can provide technical support through video communication.

4. If bad quality problems occur, our salesmen and technicians will personally go to your company to inspect and repair, and offer solutions.




Contact Details
Shenzhen Exlentech Welding Equipments Co., Ltd.

Contact Person: kalvin

Tel: 18607555194

Send your inquiry directly to us (0 / 3000)
