Product Details:
|
| Name:: | Inverter MIG Welding Machine | Protection Gas:: | CO2 |
|---|---|---|---|
| Color:: | Customized | Brand:: | Customized |
| Input Voltage:: | 220v/380v | Wire Feeder:: | Separate |
| High Light: | 250A Pulse Mig Welder,380v Pulse Mig Welder,250A small mig welder |
||
Energy Saving 250A Pulse Mig Welder 220v 380v For 0.8mm Wire
Inverter MIG welding machine MIG-250 Separate Wire feeder input voltage 220v/380v suitable for 0.8mm wire
MIG welding machine features:
1. Suitable for flux welding wire (no gas ) and solid welding wire (with gas )
2. Energy saving,high duty cycle and performances,fan cooled
3. Precise control of current wave and voltage .
4. Overload protective circuit
5. 230V or 380V as you want/
6. Stepless power controlcompete with welding torch , earth clamp .
| Model: | MIG/NBC-250F |
| Input power Voltage Frequency(V,Hz): | AC220/380±15%,50/60 |
| Rated input power capacity(KVA) : | 8.3 |
| Rated output current(A): | 250 |
| Rated output voltage(V): | 26.5 |
| Duty cycle (%): | 60 |
| Output current range.(A): | 50-250 |
| Output voltage range(V): | 16.5-26.5 |
| Insulation class: | F |
| Case protection degree: | IP21S |
| Overall dimension(mm): | 480×204×303 |
| Weight(KG): | 18 |
| Efficiency(%): | 85 |
| Feeding speed(m/min): | 2.5-13 |
| Type of wire feeder: | Separate |
| Diameter of the wire feeder(mm): | 270 |
| Post-flow time(S): | 1±0.5 |
| Power factor (COSφ): | 0.93 |
| Earth wire(mm2): | >6 |
| Welding thickness(mm): | >0.8 |
| Diameter of welding wire(mm): | >0.8/1.0 |
FAQ
MOQ:
· If you need OEM service or need to distribute our brand? the quantity will be different accordingly,and different model with different MOQ. Please Contact us for more information.
· If you need small quantity for your own use, and you can accept our brand,small quantity could be acceptable.
Payment:
· TT/ LC/Paypal/Western Union etc.TT payment would be preferred for bulk quantity order: 30% deposit and the balance 70% before the shipment.
Delivery time:
· Sample order or small quantity order,we can delivery within 3 days.
· OEM service or other big order,it takes around 20 days after confirming the advance payment
Samples:
Can we mix different items in one container?
· Yes,you can order different model to mix one container,and even you need some other products,we would like to offer help.
What about the after sales service?
Contact Person: kalvin
Tel: 18607555194
